V760 EX

Okuma
The V760EX vertical lathe increases productivity by providing stable machining of thin and odd-shaped workpieces. With a max turning diameter of 760mm and max turning height of 770mm, this machine is capable of performing powerful, heavy-duty cuts, while the vertical orientation is the ideal platform for running thin-walled parts without distortion. The milling (M) function adds flexibility to handle a wide range of parts. The box-type base and column make a highly dependable, highly rigid structure and the headstock with flange construction minimizes the effects of thermal deformation and vibration - ensuring stable accurate cutting. The base is designed for smooth chip flow, and the optional chip conveyor can be placed for side or rear disposal to meet shop requirements. The ergonomical design includes easy access to the chuck and a front-skirt operation panel convenient for up-close jobs in addition to the swiveling pendant operation panel.

Teknisk data

  • Max. turning Ø [mm]760
  • Max. turning length [mm]770
  • Spindle speed [min-1]2.200
  • No. of tools12
  • Motor (VAC) [kW]30/22 (40/30)
  • Rapid traverse X-Z [m/min]24/24
  • Floor space [mm]1.842 × 3.115
  • Features M
